  TAL-US 系列歐化三相分手式真空填料機是在原有三相分手式填料機根本上，開辟設想的一款功效壯大、表面雅觀、裝配操縱簡潔的填料機。各機型接納不銹鋼料門，確保質料不受凈化 ; 接納高壓風機為能源焦點，具有不易破壞，吸力大，利用壽命長等
特色。另供給經濟型機種供客戶挑選。TAL-US 系列真空粉體填料機，它具有 TAL-US 系列產物的統統特色，同時，還有雙段風機
可供選配 ; 按照其在用戶真個差別利用景象，可挑選裝載差別過濾器的料桶 , 合用于含粉量 30% 及 100% 的保送功課。
TAL-US | 系列
The TAL-US series Europeanized three-phase separation vacuum packing machine is a powerful, aesthetically pleasing, and easy to
install and operate packing machine developed and designed on the basis of the original three-phase separation packing machine. Each
model adopts stainless steel material doors to ensure that raw materials are not contaminated; Using high-pressure fans as the power
core, it has the characteristics of being not easily damaged, having high suction force, and long service life. We also provide economical
models for customers to choose from. The TAL-US series vacuum powder filler machine has all the characteristics of the TAL-US series
products, and there is also a dual stage fan available for optional configuration; According to its different usage on the user end, different
filter buckets can be selected for loading, suitable for conveying operations with powder content of 30% and 100%.  微處置器配影象本利用 EEPROM, 不會喪失設定材料可永遠保管； 下吸風式設想 , 濾清器下搭配旋風擋板與分手式的集塵桶 , 有用地加重濾清器的負荷 ; 可間接設置裝備擺設歐化兩料比例 閥閥體利用 ;
料斗可選配主動洗濯裝配 , 附布質濾網 , 機型后加注“C”,TAL-12U-C/CE 以上機型可額定選配儲壓罐，機型前面加注“A”;
可依客戶需要供給經濟型系列 , 下降本錢 ( 經濟型機設置裝備擺設布質濾網 , 并打消二渡過濾網 );
供給多功效裝配架 HMB-900 供選配******調劑直徑為 900mm;
供給規范型和保溫型歐化集料斗 TAL-6U/12U/24U 供選配 (TAL-UGP 系列除外 );
TAL-UG 系列共有兩種過濾器裝配，布袋式與板式，合用于 30% 及 100% 含粉量的保送功課 , 可按照客戶需要做搭配 , 儲壓罐 , 主動噴洗裝配為規范設置裝備擺設 ;
TAL-1HP/2HP-UG 可選配旋風集塵器 ;
TAL-UGP 系列主機裝備單、雙段風機 (3.5HP 以上 ) 可供客戶之需要 ;
TAL-UG 系列當保送的質料傍邊 , 破壞料占 30% 以上時，可選配 14 目標不銹鋼濾網 ;
改成歐規寧靜回路機型時，機型后加注“CE”。
The microprocessor with memory book uses EEPROM, which will not lose setting data and can be permanently saved;
The downward suction design is equipped with a cyclone baffle and a separate dust collection bucket under the filter, effectively reducing the load on the filter; Can be directly configured
with a Europeanized two material proportional valve body for use;
The hopper can be equipped with an automatic cleaning device and a fabric filter. The model can be filled with "C", and models above TAL-12U-C/CE can be additionally equipped with a
pressure storage tank. The model can be filled with "A" at the back;
We can provide economy series according to customer needs to reduce costs (economy machines are equipped with fabric filters and secondary filters are eliminated);
Provide multifunctional mounting bracket HMB-900 for optional maximum adjustment diameter of 900mm;
Provide standard and insulated Europeanized aggregate hoppers TAL-6U/12U/24U for optional configuration (excluding the TAL-UGP series);
The TAL-UG series has two types of filter devices, bag type and plate type, suitable for conveying operations with 30% and 100% powder content. They can be matched according to
customer needs. The pressure storage tank and automatic spray washing device are standard configurations;
TAL-1HP/2HP-UG can be optionally equipped with a cyclone dust collector;
The TAL-UGP series host is equipped with single and double stage fans (above 3.5HP) to meet the needs of customers;
When more than 30% of the raw materials conveyed by the TAL-UG series are crushed materials, a 14 mesh stainless steel filter can be optionally equipped;
When changing to a European safety circuit model, add "CE" after the model  |
|
